The PCA9306DC1,125 is a versatile and robust level translating device engineered by NXP Semiconductors, designed to address the challenges of communication between devices operating at different voltage levels. This level shifter is particularly useful in applications where the need for low-voltage components to interface with higher voltage systems is prevalent.

Key Features

• Bidirectional Translation: The PCA9306DC1,125 allows for seamless bidirectional voltage level translation between two different logic level voltages ranging from 1.2V to 3.3V on one side and 1.8V to 5.5V on the other side, which is essential for interfacing between low-voltage microcontrollers and standard-voltage peripherals.
• I2C and SMBus Compatible: This device is designed to work with the I2C-bus and other SMBus applications, ensuring compatibility with a wide range of communication protocols and devices.
• No Direction Control: The PCA9306DC1,125 does not require an external direction control signal, simplifying the design and reducing the overall component count.
• Low Standby Current: It features a low standby current which is beneficial for battery-powered devices, helping to extend battery life and reduce power consumption.

Applications

The device is ideal for a multitude of applications where voltage level translation is required, such as:

• Mobile devices, where interfacing between low-voltage processors and higher voltage peripheral components is necessary.
• Consumer electronics that require connections between different voltage domains within the system.
• Industrial and automotive applications where robust level shifting is required to interface between control units and sensors or actuators.

Product Specifications

The PCA9306DC1,125 from NXP Semiconductors is a highly integrated solution for your voltage level translation needs, offering reliability and flexibility in a compact form factor.
