PSMN1R7-60BS - NXP MOSFET Overview

The PSMN1R7-60BS is a high-performance, N-channel enhancement mode Field Effect Transistor (MOSFET) produced by NXP Semiconductors. Designed to deliver efficiency and power density in a compact package, this MOSFET is a suitable choice for a wide range of applications, including power supply, DC-DC conversion, motor control, and automotive systems.

Key Features

• Low On-Resistance: The PSMN1R7-60BS boasts a low on-resistance (R<sub>DS(on)) of just 1.7 mΩ at V<sub>GS = 10 V, which means it has minimal conduction losses and is highly efficient in passing current.
• High Current Capability: With a continuous drain current (I<sub>D) rating of up to 100 A, this MOSFET can handle high-power applications with ease.
• 60V Drain-Source Voltage: The device can withstand drain-source voltages (V<sub>DS) up to 60V, making it robust for various circuit conditions.
• Reduced Gate Charge: A low gate charge (Q<sub>G) facilitates faster switching, which is crucial for reducing switching losses and improving performance in high-frequency applications.
• TO-263 (D2PAK) Package: The PSMN1R7-60BS comes in a surface-mount TO-263 (D2PAK) package, which is known for its thermal and electrical performance, as well as its suitability for high-power applications.

Applications

• Switch Mode Power Supplies (SMPS)
• DC-DC Converters
• Power Management Functions
• Motor Drives and Inverters
• Automotive Applications

The PSMN1R7-60BS from NXP is designed to meet the stringent requirements of modern electronic circuits, providing a combination of high efficiency, reliability, and performance. Its robustness and versatility make it an ideal choice for designers looking to optimize their power management solutions across a variety of industrial and automotive applications.

Environmental and Quality Certifications

This product is compliant with the RoHS directive, ensuring that it meets the European Union's restrictions on the use of certain hazardous substances in electrical and electronic equipment. Additionally, NXP's commitment to quality is reflected in the MOSFET's adherence to industry-standard reliability testing.
