ON Semiconductor's LM2576D2T-ADJR4G: A Versatile Voltage Regulator

The LM2576D2T-ADJR4G from ON Semiconductor is a highly efficient, easy-to-use voltage regulator that comes in a TO-263 package. This regulator is part of the LM2576 series, which is known for its robustness and reliability in a wide range of applications. The device is designed to provide all the active functions necessary for a step-down (buck) switching regulator capable of driving a 3A load with excellent line and load regulation.

This voltage regulator is adjustable and features a guaranteed 3A output current. It has a wide input voltage range from 4.75V to 40V, making it suitable for a variety of applications, from simple low-power electronics to complex industrial systems. The adjustable output voltage range is from 1.23V to 37V, which provides the user with a flexible solution for custom voltages.

One of the key features of the LM2576D2T-ADJR4G is its high efficiency, which can reach up to 92%, depending on the input and output voltages. This efficiency is achieved through the use of a simple and straightforward fixed-frequency PWM control circuit that requires a minimum number of external components. The regulator operates at a fixed frequency of 52kHz which allows for the use of smaller and less expensive inductors and capacitors, resulting in a compact power supply design.

The device includes a host of protection features to ensure the safety and longevity of your electronic designs. These include thermal shutdown, cycle-by-cycle current limiting, and a safe area protection for the output switch. Furthermore, the LM2576D2T-ADJR4G is characterized for operation from −40°C to +125°C, making it suitable for even the most challenging environmental conditions.

Whether you're designing power supplies for consumer electronics, office equipment, or industrial machinery, the LM2576D2T-ADJR4G is a reliable and versatile choice that combines ease of use with high performance. Its TO-263 package ensures a compact footprint while providing adequate thermal performance for most applications.

ON Semiconductor's commitment to quality and performance is evident in the LM2576D2T-ADJR4G, making it an excellent choice for designers looking for a robust and efficient voltage regulation solution.
