Product Overview: MC74HC125ANG from ON Semiconductor

The MC74HC125ANG is a high-performance integrated circuit produced by ON Semiconductor, a leader in energy-efficient electronics innovation. This device is a quad buffer/line driver with 3-state outputs, designed to interface with bus lines in a digital system where driving capabilities and data flow control are crucial.

Fabricated with silicon gate CMOS technology, the MC74HC125ANG ensures low power consumption and a broad operating voltage range, making it an excellent choice for battery-operated and portable applications. Its operating voltage ranges from 2V to 6V, providing flexibility for use in various circuit designs.

Each buffer of the MC74HC125ANG has a separate output enable input, which controls the 3-state output. When the output enable input is high, the output is in a high impedance state, which means it is neither driving nor sinking current. This feature allows for the connection of multiple outputs to a common bus line without the risk of current flowing between outputs, ensuring safe multiplexing and data routing.

The MC74HC125ANG's inputs are designed to be tolerant to higher input voltages, even when the device is powered off, providing additional protection and reliability to the system. Its fast propagation delay and transition times make it suitable for high-speed operations.

ON Semiconductor's commitment to quality ensures that the MC74HC125ANG meets stringent standards for performance and reliability. The device is available in a standard 14-pin DIP (Dual In-line Package) format, making it easy to integrate into a wide range of electronic circuits.

Whether you're designing consumer electronics, communication devices, or complex computer systems, the MC74HC125ANG from ON Semiconductor is an excellent choice for ensuring robust and efficient signal driving capabilities.
