ON Semiconductor MC74HC4052F Analog Multiplexer/Demultiplexer

The ON Semiconductor MC74HC4052F is a versatile and high-performance analog multiplexer/demultiplexer integrated circuit that is part of the HC4052 family. This device is meticulously designed to handle analog signals over a wide range of digital and analog voltages, making it an excellent choice for various applications in signal routing.

Key Features

• Dual 4-Channel Multiplexing: The MC74HC4052F offers two independent 4-channel multiplexers, allowing for flexible signal routing options.
• Wide Voltage Range: It can operate with a digital control input voltage from 2V to 6V and an analog input signal range from -5V to +5V when the VCC is 5V.
• Low ON Resistance: The device features a low ON resistance (RON) which typically stands at 70Ω over the full analog input range, ensuring minimal signal attenuation.
• Low Crosstalk: Designed with low crosstalk between multiplexer channels, the MC74HC4052F preserves signal integrity, ensuring clear and accurate signal routing.
• Break-Before-Make Switching: This feature prevents momentary shorting of channels during switching, which is critical for the protection of sensitive circuits.
• ESD Protection: The device includes built-in ESD protection circuits to safeguard against electrostatic discharges, enhancing its durability and reliability.

Applications

The MC74HC4052F is suitable for a broad range of applications, including but not limited to:

• Analog signal routing and multiplexing
• Data acquisition systems
• Communication systems
• Audio and video signal processing
• Industrial control systems

Package and Quality

The MC74HC4052F comes in a compact SOP-16 package, ensuring a minimal footprint on printed circuit boards (PCBs). ON Semiconductor is committed to high-quality standards, and this product is no exception, offering reliable performance for both commercial and industrial temperature ranges.

Whether you're designing a complex communication system or a simple signal routing solution, the MC74HC4052F from ON Semiconductor provides the flexibility, reliability, and performance you need to create an efficient and effective design.
