ON Semiconductor NCP163AFCT300T2G Low Dropout Voltage Regulator

The ON Semiconductor NCP163AFCT300T2G is a state-of-the-art low dropout (LDO) voltage regulator designed to deliver a fixed output of 3.0V with an input voltage range from 1.4V to 5.5V. This high-accuracy device is optimized for low-power applications and provides a stable and reliable power supply, making it an ideal choice for a wide range of electronic devices.

Key Features

• High Output Voltage Accuracy: The NCP163AFCT300T2G offers an impressive ±1% output voltage accuracy under all line, load, and temperature conditions, ensuring that your device operates consistently and effectively.
• Ultra-Low Dropout: With a typical dropout of just 135mV at 300mA load, this LDO regulator maintains efficiency and provides a stable output even when the input voltage is close to the output voltage.
• Low Quiescent Current: It features a very low quiescent current of typically 20µA, which is ideal for battery-powered applications where extending battery life is crucial.
• Thermal Shutdown and Current Limit: The device includes built-in thermal shutdown and current limit features to protect the regulator and the load from over-temperature and over-current conditions.
• Noise Reduction: The NCP163AFCT300T2G is designed to offer low output noise, making it suitable for sensitive RF and analog circuits that require a clean power supply.

Applications

The NCP163AFCT300T2G is versatile and can be used in various applications, including:

• Portable and Battery-Powered Devices
• Wireless Handsets and WiFi Modules
• Wearable Technology
• Medical Devices
• IoT Devices
• Microcontroller Power Supply

Package and Reliability

This LDO comes in a compact, space-saving 1 mm x 1 mm x 0.4 mm XDFN-4 package, which is perfect for space-constrained applications. The NCP163AFCT300T2G is designed for high reliability, as evidenced by ON Semiconductor's commitment to rigorous quality control and industry standards.

Environmental and Regulatory Compliance

ON Semiconductor ensures that the NCP163AFCT300T2G complies with environmental regulations, including RoHS and Pb-Free standards, making it an environmentally friendly choice for manufacturers concerned with sustainability.

In summary, the NCP163AFCT300T2G from ON Semiconductor is an excellent choice for designers looking for a high-performance, reliable, and efficient LDO voltage regulator for their low-power applications.
