SMP3003-DL-E ON Semiconductor – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

SMP3003-DL-E

Part No SMP3003-DL-E
Manufacturer ON Semiconductor
Catalog Transistors – FETs, MOSFETs – Single
Description MOSFET P-CH 75V 100A SMP-FD
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
FET Type P-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 75 V
Current - Continuous Drain (Id) @ 25°C 100A (Ta)
Rds On (Max) @ Id, Vgs 8mOhm @ 50A, 10V
Gate Charge (Qg) (Max) @ Vgs 280 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds 13400 pF @ 20 V
Power Dissipation (Max) 90W (Tc)
Mounting Type Surface Mount
Supplier Device Package SMP-FD
Case / Package TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1495241-SMP3003-DL-E
Ultra Librarian 3D Model Ultra Librarian SMP3003-DL-E CAD Model

Description

N
