2SC4420 Real Image
Same model may have multiple batches, images only for reference.

2SC4420

Part No 2SC4420
Manufacturer Panasonic
Catalog Transistors (BJT) - Single
Description TRANS NPN 800V 3A TOP-3F
Datasheet
2SC4420 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Panasonic Electronic Components
Packaging Bulk
Status Obsolete(EOL)
Transistor Polarity NPN
Maximum Current Collector 3A
VCEO Maximum Collector-Emitter Breakdown Voltage 800V
Max Vce (sat) 1.5V @ 160mA, 800mA
Collector Cut-off Current(Max) 50μA (ICBO)
Typical Gain (hFE) (Min) 6 @ 800mA, 5V
Maximum Power Dissipation 3W
Frequency - Transition 10MHz
Temperature Range - Operating 150°C (TJ)
Mounting Through Hole
Case / Package TOP-3F-A1
Win Source Part Number 1004423-2SC4420
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian 2SC4420 CAD Model

Description

The Panasonic Electronic Components 2SC4420 is an NPN transistor with a maximum collector current of 3A and a collector-emitter breakdown voltage of 800V.

  • Transistor Type: NPN
  • Maximum Collector Current: 3A
  • Collector-Emitter Breakdown Voltage: 800V
  • Frequency Transition: 10MHz
  • Operating Temperature Range: 150°C (TJ)
  • Typical Gain: 6 @ 800mA, 5V
  • Maximum Power Dissipation: 3W
  • Package: TOP-3F-A1
  • Popularity: Medium
  • Supply and Demand Status: Sufficient
  • Status: Obsolete (End of Life)
