JK1A-12V Real Image
Same model may have multiple batches, images only for reference.

JK1A-12V

Part No JK1A-12V
Manufacturer Panasonic
Catalog Power Relays, Over 2 Amps
Description SLIM TYPE POWER RELAY | RELAY GEN PURPOSE SPST 3A 12V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Panasonic Electric Works
Packaging Bulk
Status Obsolete
Mounting Style Through Hole
Coil Voltage 12VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 3A
Switching Voltage 250VAC, 110VDC - Max
Coil Current 17.0mA
Coil Type Non Latching
Termination Style PC Pin
Seal Rating Sealed - Fully
Must Operate Voltage 9.6 VDC
Must Release Voltage 0.6 VDC
Operate Time 4ms
Release Time 2ms
Temperature Range - Operating -40°C ~ 70°C
Contact Material Silver Alloy
Relay Type General Purpose
Coil Resistance 720 Ohms
Manufacturer Pack Quantity 100
MSL Level Not Applicable
Win Source Part Number 1191593-JK1A-12V
Manufacturer Homepage 0
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian JK1A-12V CAD Model

Description

The JK1A-12V is a non-latching relay from Panasonic Electric Works that features a single pole single throw normally open contact form and a coil voltage of 12VDC.

  • Contact Form: Single Pole Single Throw Normally Open
  • Coil Voltage: 12VDC
  • Contact Rating: 3A
  • Switching Voltage: Up to 250VAC or 110VDC
  • Coil Resistance: 720 Ohms
  • Maximum Operate Time: 4ms
  • Component Type: Through-Hole
  • Packaging: Bulk
  • Temperature Range: -40°C to 70°C
  • Status: Obsolete
  • Supply and Demand Status: Limited
