HAT2165H-EL-E Real Image HAT2165H-EL-E Real Image
Same model may have multiple batches, images only for reference.
HAT2165H-EL-E Real Image HAT2165H-EL-E Real Image
HAT2165H-EL-E Real Image HAT2165H-EL-E Real Image
Same model may have multiple batches, images only for reference.

HAT2165H-EL-E

Part No HAT2165H-EL-E
Manufacturer Renesas Electronics America
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH Si 30V 55A 5-Pin(4+Tab) LFPAK T/R / MOSFET N-CH 30V 55A LFPAK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Renesas Electronics America
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 55A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 1mA
Max Gate Charge 33nC @ 4.5V
Max Input Capacitance 5180pF @ 10V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 30W (Tc)
Maximum Rds On at Id,Vgs 3.3 mOhm @ 27.5A, 10V
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Case / Package LFPAK
Dimension SC-100, SOT-669
Win Source Part Number 067800-HAT2165H-EL-E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name HAT2165H
Introduction Date April 10, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Not Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian HAT2165H-EL-E CAD Model

Description

The Renesas HAT2165H is a N-channel MOSFET designed for use in discrete semiconductor products. It is a common-used part with high popularity and has a balanced supply and demand status.

  • Maximum Power Dissipation: 30W
  • Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current: 55A @ 25°C
  • Gate-Source Threshold Voltage: 2.5V @ 1mA
  • Maximum Gate Charge: 33nC @ 4.5V
  • Maximum Rds On: 3.3 mOhm @ 27.5A, 10V
  • Package: LFPAK
  • Dimensions: SC-100, SOT-669
  • Estimated EOL Date: 2022
  • Halogen-Free: No
