NP20P06SLG-E1-AY Real Image NP20P06SLG-E1-AY Real Image
Same model may have multiple batches, images only for reference.
NP20P06SLG-E1-AY Real Image NP20P06SLG-E1-AY Real Image
NP20P06SLG-E1-AY Real Image NP20P06SLG-E1-AY Real Image
Same model may have multiple batches, images only for reference.

NP20P06SLG-E1-AY

Part No NP20P06SLG-E1-AY
Manufacturer Renesas Electronics America
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 60V 20A TO-252
Datasheet
NP20P06SLG-E1-AY Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Renesas Electronics America
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 20A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 250μA
Max Gate Charge 34nC @ 10V
Max Input Capacitance 1650pF @ 10V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 1.2W (Ta), 38W (Tc)
Maximum Rds On at Id,Vgs 48 mOhm @ 10A, 10V
Temperature Range - Operating 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252 (MP-3ZK)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 1083309-NP20P06SLG-E1-AY
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name NP20P06SLG
Introduction Date December 19, 2007
ECCN EAR99
Country of Origin Japan, Malaysia
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian NP20P06SLG-E1-AY CAD Model

Description

The Renesas Electronics America NP20P06SLG-E1-AY is a P-channel MOSFET designed for discrete semiconductor products.

  • Channel Type: P-channel
  • Drain-Source Breakdown Voltage: 60V
  • Continuous Drain Current @ 25°C: 20A (Tc)
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Rds On @ Id, Vgs: 48 mOhm @ 10A, 10V
  • Gate-Source Threshold Voltage: 2.5V @ 250μA
  • Max Gate Charge: 34nC @ 10V
  • Maximum Input Capacitance: 1650pF @ 10V
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Package: TO-252 (MP-3ZK)
  • Dimension: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Introduction Date: December 19, 2007
  • Estimated EOL Date: 2025
