STW9C2SB Seoul Semiconductor Inc.
Same model may have multiple batches, images only for reference.

STW9C2SB

Part No STW9C2SB
Manufacturer Seoul Semiconductor Inc.
Catalog LED Lighting - White
Description LED WHITE SMD
Datasheet
STW9C2SB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics - White LED Lighting
Mfr Seoul Semiconductor Inc.
Series 3030
Package Tape & Reel
Product Status Active
Color White
Current - Test 100mA
Voltage - Forward (Vf) (Typ) 6.1V
CRI (Color Rendering Index) 90
Current - Max 200mA
Viewing Angle 120°
Mounting Type Surface Mount
Package / Case 1212 (3030 Metric)
Supplier Device Package 3030
Size / Dimension 0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max) 0.031" (0.80mm)
Thermal Resistance of Package 10°C/W
Base Product Number STW9C2
Standard Package 4,500 pcs
ECCN EAR99
HTSUS 8541.41.0000
Win Source Part Number 804527-STW9C2SB
Ultra Librarian 3D Model Ultra Librarian STW9C2SB CAD Model

Description

The Seoul Semiconductor Inc. 804527-STW9C2SB is a white LED lighting component.

  • Series: 3030
  • Color: White
  • Packaging: Tape and Reel
  • Standard Package: 4,500 pieces
  • Maximum Current: 200mA
  • Viewing Angle: 120°
  • Forward Voltage (Vf): 6.1V (approximately)
  • CRI: 90
  • Thermal Resistance: 10°C/W
  • Mounting: Surface Mount
  • Package/Case: 1212 (3030 metric)
  • ECCN: EAR99
  • HTSUS Code: 8541.41.0000
