NP05-2A66-500-220 Real Image
Same model may have multiple batches, images only for reference.

NP05-2A66-500-220

Part No NP05-2A66-500-220
Manufacturer Standex-Meder Electronics
Catalog Signal Relays, Up to 2 Amps
Description RELAY REED DPST 500MA 5V /
Datasheet
NP05-2A66-500-220 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays>Reed Relays
Mfr Standex-Meder Electronics
Series NP
Package Tube
Mounting Type Through Hole
Coil Voltage 5VDC
Contact Form DPST-NO (2 Form A)
Contact Rating (Current) 500 mA
Switching Voltage 200VAC, 200VDC - Max
Coil Current 10 mA
Coil Type Non Latching
Features EMI Shielded
Termination Style PC Pin
Must Operate Voltage 3.5 VDC
Must Release Voltage 0.75 VDC
Operate Time 0.5 ms
Release Time 0.1 ms
Temperature Range - Operating -20°C ~ 70°C
Coil Resistance 500 Ohms
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.41.0030
Other Names 3105271220,NPO5-2A66-500-220
Standard Package 48
Win Source Part Number 1162068-NP05-2A66-500-220
Ultra Librarian 3D Model Ultra Librarian NP05-2A66-500-220 CAD Model

Description

This DPST-NO (2 Form A) reed relay is part of the NP series and features PC pin termination style, EMI shielding, and a tube package.

  • Contact Rating for Current: 500mA
  • Maximum Switching Voltage: 200VAC and 200VDC
  • Coil Voltage: 5VDC
  • Coil Resistance: 500 Ohms
  • Coil Current: 10mA
  • Operate Time: 0.5ms
  • Release Time: 0.1ms
  • Mounting: Through-hole mounted
  • Temperature Range: -20°C to 70°C
  • Manufacturer: Standex-Meder Electronics
  • ECCN: EAR99
  • Must Operate Voltage: 3.5VDC
  • Must Release Voltage: 0.75VDC
  • HTSUS Code: 8536.41.0030
