The M74HC4094RM13TR is a high-performance, integrated circuit designed and manufactured by STMicroelectronics, a global semiconductor leader. This device is part of the HC family, which signifies that it is a high-speed CMOS device designed to operate with the speed of advanced CMOS devices while maintaining the low power consumption of standard CMOS integrated circuits.

Key Features

• Device Type: 8-stage shift-and-store bus register
• Logic Family: HC
• Logic Type: Serial to Parallel
• Output Type: Tri-State
• Number of Circuits: 1
• Number of Bits per Element: 8
• Supply Voltage Range: 2V to 6V
• Operating Temperature Range: -55°C to +125°C
• Mounting Type: Surface Mount
• Package / Case: SOIC-16
• Packaging: Tape & Reel (TR)

Product Description

The M74HC4094RM13TR is a high-speed CMOS 8-stage shift-and-store bus register with 3-state outputs. This device is tailored for serial to parallel data conversion and is commonly used in applications that require the acquisition and control of data. It accepts serial input data and outputs it in a parallel format. The 3-state outputs can be connected directly to a bus-organized system, providing a high degree of flexibility in bus management.

With a wide operating voltage range from 2V to 6V, the M74HC4094RM13TR provides compatibility with a variety of logic levels, ensuring its use in mixed-voltage systems. The device also features a high noise immunity characteristic of CMOS devices, which is crucial for stable performance in electrically noisy environments.

The M74HC4094RM13TR comes in a compact SOIC-16 package and is designed for surface mount technology, making it suitable for high-density mounting and saving valuable PCB space. The device is provided in tape and reel packaging, facilitating automated assembly processes and volume production.

STMicroelectronics' commitment to quality and reliability is evident in the M74HC4094RM13TR's design, making it an excellent choice for a wide range of industrial, commercial, and consumer applications where a reliable shift-and-store bus register is required.
