STB25NM60ND - N-Channel MOSFET from STMicroelectronics

The STB25NM60ND is a high-performance N-Channel MOSFET designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This power MOSFET is engineered to deliver efficiency and reliability for a wide range of applications, making it an ideal choice for designers looking to optimize their power management systems.

Key Features

• Voltage Rating: The device has a drain-to-source voltage (V<sub>DS) of 600V, making it suitable for high-voltage applications.
• Current Capability: It boasts a continuous drain current (I<sub>D) of 20A, ensuring it can handle significant power loads.
• R<sub>DS(on): With a low on-resistance of typically 0.19 ohm, the STB25NM60ND ensures high efficiency and reduced heat dissipation during operation.
• Fast Switching: The device offers fast switching performance, which is critical for reducing switching losses and improving power efficiency.
• Enhanced Durability: Its robust design is characterized by high ruggedness and immunity to the effects of hard commutation in inductive loads.

Applications

The STB25NM60ND is versatile and can be used in a range of applications, including:

• Switch Mode Power Supplies (SMPS)
• High-efficiency DC/DC converters
• Motor control applications
• Power factor correction circuits
• LED lighting solutions

Quality and Reliability

STMicroelectronics is committed to delivering products that meet the highest standards of quality and reliability. The STB25NM60ND is no exception, and it is manufactured to ensure consistent performance and longevity, even under challenging conditions. It is also compliant with RoHS and Halogen-Free standards, reflecting ST's dedication to environmental sustainability.

Design Support

Designers can take advantage of ST's comprehensive technical support and resources, including datasheets, application notes, and simulation tools, to facilitate the integration of the STB25NM60ND into their designs. With its combination of performance, efficiency, and support, the STB25NM60ND is a compelling solution for power management challenges.
