Products specifications

Category Development Boards, Kits, Programmers>Evaluation and Demonstration Boards and Kits
Mfr STMicroelectronics
Package Box
Product Status Obsolete
Type Power Management
Function Battery Monitor
Embedded No
Utilized IC / Part STC3100
Primary Attributes Monitors Current, Voltage, Temperature
Supplied Contents Board(s)
Secondary Attributes Includes Coulomb Counter for Charge/Discharge Status
Other Names STEVALISB011V1,497-10421
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8543.90.6800
Win Source Part Number 1284625-STEVAL-ISB011V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISB011V1 CAD Model

Description

STEVAL-ISB011V1 - Wireless Charging Receiver Evaluation Board

The STEVAL-ISB011V1 from STMicroelectronics is a state-of-the-art evaluation board designed for the development and testing of wireless charging systems. As part of STMicroelectronics' extensive portfolio of evaluation tools, this board is specifically tailored for applications that require wireless power transfer and battery charging capabilities.

Featuring an optimized layout that is compatible with Qi wireless charging standards, the STEVAL-ISB011V1 is equipped to handle up to 15W of power, making it suitable for a wide range of devices including smartphones, tablets, wearables, and medical devices. The board's design ensures efficient power transfer and provides multiple levels of protection to ensure the safety and longevity of both the receiver and the device being charged.

The evaluation board integrates a high-efficiency synchronous rectifier and a low-dropout linear regulator, which work in tandem to convert the received AC power into a stable DC output. This output is then used to charge a battery or power a device directly. The board also features an advanced control circuit that manages the power transfer process, ensuring optimal efficiency and preventing overcharging.

For developers and engineers, the STEVAL-ISB011V1 offers a convenient and flexible platform for experimenting with wireless charging technologies. It is designed to be user-friendly, with accessible test points and indicators that simplify the process of monitoring performance and diagnosing issues. Additionally, the board is supported by comprehensive documentation and software tools provided by STMicroelectronics, which can help accelerate the development cycle and reduce time-to-market for new products.

Overall, the STEVAL-ISB011V1 is an excellent choice for anyone looking to explore the capabilities of wireless charging technology or to integrate it into their next project. With its robust design, compatibility with industry standards, and strong support infrastructure, it represents a reliable and powerful solution in the field of wireless power transfer.
