The STK22N6F3 is a high-performance, N-channel Power MOSFET designed and manufactured by the renowned semiconductor company, STMicroelectronics. This MOSFET is part of ST's STripFET F3 series, which is known for its low on-resistance and low gate charge, making it an excellent choice for high-efficiency power management applications.

Key Features

• High Current Capability: The STK22N6F3 offers a maximum continuous drain current (I_D) of 22A, making it suitable for handling high current loads.
• Low On-Resistance: With an R_DS(on) of just 6 mΩ (max), this MOSFET ensures minimal power loss and heat generation during operation.
• High Switching Efficiency: The low gate charge (Q_g) and capacitance of the STK22N6F3 facilitate fast switching, which is essential for reducing switching losses in power conversion circuits.
• Voltage Rating: It is designed to withstand a maximum drain-source voltage (V_DSS) of 60V, offering a good safety margin for most low to medium voltage applications.
• Thermal Performance: The device is encapsulated in a TO-220 package, which provides excellent thermal performance and is easy to mount on a heatsink for enhanced thermal management.

Applications

The STK22N6F3 is versatile and can be used in a variety of applications, including:

• Switch Mode Power Supplies (SMPS)
• DC-DC Converters
• Motor Drives
• LED Lighting
• Automotive Applications
• Power Management Functions

Quality and Reliability

STMicroelectronics is known for its commitment to quality and reliability, and the STK22N6F3 is no exception. It is designed to meet the stringent requirements of the industrial and automotive markets, ensuring long-term reliability and performance under various operating conditions.

Environmental Compliance

The STK22N6F3 is compliant with RoHS and Halogen-Free standards, reflecting STMicroelectronics' dedication to environmental sustainability and the reduction of hazardous substances in electronic components.
