The Texas Instruments CSD18513Q5A is a state-of-the-art N-Channel NexFET™ power MOSFET designed to deliver high performance in power management applications. This compact and efficient MOSFET is an ideal choice for a wide range of applications, including synchronous buck converters, server and telecom power supplies, and other power conversion systems that require a high-efficiency power switch.

Key Features

• Low On-Resistance: The CSD18513Q5A boasts an ultra-low on-resistance (R<sub>DS(on)) of only 2.5 mΩ at a V<sub>GS of 10 V, resulting in minimized conduction losses and enhanced overall efficiency.
• High Continuous Drain Current: It supports a high continuous drain current (I<sub>D) of up to 100 A, making it suitable for high-power applications.
• Advanced Thermal Performance: With its power-saving and thermal-efficient design, the CSD18513Q5A ensures reliable operation even under high temperature conditions.
• SON 5mm x 6mm Package: The compact footprint of the CSD18513Q5A allows for space-saving PCB designs without compromising power handling capabilities.
• RoHS Compliant: Adhering to environmental standards, this MOSFET is RoHS compliant, reducing the environmental impact and meeting global regulatory requirements.

Applications

• DC/DC Power Supplies
• Motor Control Systems
• Power Delivery Solutions
• Point of Load (POL) Modules
• Telecom and Server Power Systems

The CSD18513Q5A from Texas Instruments is a robust and efficient solution for engineers looking to improve the performance and reliability of their power management systems. With its excellent thermal characteristics, low on-resistance, and high current capability, this MOSFET is engineered to meet the rigorous demands of modern electronic devices.

For detailed specifications and application notes, visit the Texas Instruments product page.
