CSD97376Q4M Real Image CSD97376Q4M Real Image1 CSD97376Q4M Real Image2 CSD97376Q4M Real Image3 CSD97376Q4M Real Image4 CSD97376Q4M Real Image5
Same model may have multiple batches, images only for reference.
CSD97376Q4M Real Image CSD97376Q4M Real Image1 CSD97376Q4M Real Image2 CSD97376Q4M Real Image3 CSD97376Q4M Real Image4 CSD97376Q4M Real Image5
CSD97376Q4M Real Image CSD97376Q4M Real Image1 CSD97376Q4M Real Image2 CSD97376Q4M Real Image3 CSD97376Q4M Real Image4 CSD97376Q4M Real Image5
Same model may have multiple batches, images only for reference.

CSD97376Q4M

Part No CSD97376Q4M
Manufacturer Texas Instruments
Catalog PMIC - Full, Half - Bridge Drivers
Description Synchronous Buck FET Smart Power Stage / IC SYNC BUCK NEXFET 8VSON
Datasheet
CSD97376Q4M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Not For New Designs
Applications Synchronous Buck Converters
Load Type Inductive
Technology Power MOSFET
Channel Output Current 20A
Current - Peak Output 45A
Supply Voltage - Operating 4.5 V to 5.5 V
Voltage - Load 4.5 V to 24 V
Temperature Range - Operating -40°C to 150°C (TJ)
Features Bootstrap Circuit
Fault Protection Shoot-Through, UVLO
Mounting SMD (SMT)
Case / Package 8-VSON (3.5x4.5)
Win Source Part Number 013384-CSD97376Q4M
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name CSD97376Q4M
Introduction Date March 07, 2013
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian CSD97376Q4M CAD Model

Description

Description

The CSD97376Q4M is a multi-functional power management block that delivers enhanced performance for complex electronic systems. Its integrated design optimizes efficiency and simplifies the power supply design by combining drivers and MOSFETs, suitable for high-demand applications.
