Product Overview: Texas Instruments INA219BIDR

The INA219BIDR is a high-precision current shunt and power monitor with an I2C-compatible interface. Designed and manufactured by Texas Instruments, this device provides industry-leading performance for accurate power monitoring. The INA219BIDR is capable of measuring both the voltage across a shunt resistor and the shunt current, allowing for precise calculations of power consumption.

Key Features

• High Accuracy: The INA219BIDR offers a high-precision measurement with an accuracy of 1% over a wide temperature range. This accuracy is critical for applications that require precise power management and monitoring.
• Programmable Calibration: Users can calibrate the device to measure various current levels, with the maximum sense voltage of 320mV. This programmability allows the INA219BIDR to be adapted to a wide range of applications.
• Extended Voltage Range: The device supports a wide power supply range from 3V to 5.5V, making it suitable for battery-powered and portable applications.
• High-Side Measurement: The high-side measurement capability allows for the INA219BIDR to measure voltage drop across a shunt resistor placed in the high side of the power supply, which is safer and prevents ground disturbance.
• I2C Interface: The I2C interface provides compatibility with most microcontrollers, making integration into existing systems straightforward. It supports standard (100kHz), fast (400kHz), and high-speed (3.4MHz) modes.

Applications

The INA219BIDR is versatile and can be used in various applications, including:

• Power management in servers and telecom equipment
• Battery chargers and battery-powered devices
• Energy consumption monitoring for industrial and consumer applications
• Solar power monitoring systems
• Smart power distribution systems

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability, and the INA219BIDR is no exception. It is designed to meet the stringent requirements of industrial and commercial applications, ensuring consistent performance and durability.
