LM1085ISX-ADJ

Part No LM1085ISX-ADJ
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description LM1085 3A Low Dropout Positive Regulators | IC REG LIN POS ADJ 3A DDPAK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel
Output Type Adjustable
Voltage - Input (Maximum) 29V
Min/Fixed Output Voltage 1.25V
Maximum Output Voltage 15V
Maximum Dropout Voltage 1.5V at 3A
Output Current 3A
Current - Quiescent (Iq) 10mA
PSRR 75dB (120Hz)
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Supplier Device Package DDPAK/TO-263-3
Family Part Number LM1085
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 1196649-LM1085ISX-ADJ
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM1085ISX-ADJ CAD Model

Description

LM1085ISX-ADJ from Texas Instruments is an adjustable linear voltage regulator used in power conditioning stages where designers need simple regulation, low design complexity, and dependable performance from a widely recognized PMIC supplier. It is commonly considered for industrial controls, embedded boards, telecom support rails, test equipment, and general-purpose regulation in systems that require a straightforward linear solution rather than a switching architecture. Engineers often choose devices in this category for post-regulation, noise-sensitive rails, and retrofit or maintenance projects where board simplicity and predictable behavior are important. The current lifecycle status for LM1085ISX-ADJ is information not available based on the provided input, so teams should confirm availability and long-term supply directly with Texas Instruments or authorized distributors before locking it into new designs. RoHS compliance status is also information not available here and should be verified through the official datasheet, product page, or manufacturer compliance documentation.
