LM1086CS-5.0 Real Image LM1086CS-5.0 Real Image
Same model may have multiple batches, images only for reference.
LM1086CS-5.0 Real Image LM1086CS-5.0 Real Image
LM1086CS-5.0 Real Image LM1086CS-5.0 Real Image
Same model may have multiple batches, images only for reference.

LM1086CS-5.0

Part No LM1086CS-5.0
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V 1.5A DDPAK
Datasheet
LM1086CS-5.0 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 25V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 1.5V @ 1.5A
Output Current 1.5A
Operating Supply Current 5mA to 10mA
PSRR 68dB (120Hz)
Control Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 1.3V @ 1.5A
Mounting SMD (SMT)
Case / Package DDPAK/TO-263-3
Win Source Part Number 082571-LM1086CS-5.0
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM1086CS-5.0 CAD Model

Description

The LM1086CS-5.0 from Texas Instruments is a high-performance, low-dropout voltage regulator with a fixed output voltage of 5.0V.

  • Output Current: Up to 1.5A
  • Dropout Voltage: 1.5V @ maximum output current
  • Protection Features: Current Limit, Thermal Overload Protection, and Safe Area Protection
  • Package: TO-263
