The LM285M/NOPB from Texas Instruments is a versatile, precision micropower voltage reference. This highly reliable component is an essential building block in a wide array of electronic systems. Its adjustable output voltage can be set to any value between 1.24V and 5.08V with the use of two external resistors. This feature provides flexibility and precision, making it suitable for numerous applications such as power supplies, battery-operated devices, and precision instrumentation.

Key Features

• Adjustable Output: The output voltage can be set between 1.24V and 5.08V, offering a versatile range for various applications.
• Low Quiescent Current: The device features a very low quiescent current of 20μA (typical), which is ideal for battery-powered applications where power efficiency is critical.
• Temperature Stability: The LM285M/NOPB offers excellent temperature stability, with a typical temperature coefficient of only 20ppm/°C, ensuring consistent performance across a wide temperature range.
• Wide Operating Current Range: The operating current range is from 20μA to 20mA, providing a broad operating window to accommodate different current demands.
• Extended Operating Temperature Range: This device is operational over a wide temperature range of -40°C to +85°C, making it suitable for harsh environments.

Applications

The LM285M/NOPB is a versatile component that can be used in a variety of applications, including:

• Portable, battery-powered equipment
• Power supplies
• Analog and digital electronics
• Data acquisition systems
• Automotive electronics
• Industrial control systems

Package and Quality

The LM285M/NOPB comes in an SOIC-8 package, which is a small-outline integrated circuit package that is both space-saving and easy to mount on printed circuit boards. It is also lead-free and RoHS compliant, ensuring that it meets current environmental standards. The device is part of Texas Instruments' NOPB (No Lead (Pb)) series, which indicates a commitment to environmentally friendly manufacturing practices.
