LM2936MM-3.3/NOPB Real Image LM2936MM-3.3/NOPB Real Image
Same model may have multiple batches, images only for reference.
LM2936MM-3.3/NOPB Real Image LM2936MM-3.3/NOPB Real Image
LM2936MM-3.3/NOPB Real Image LM2936MM-3.3/NOPB Real Image
Same model may have multiple batches, images only for reference.

LM2936MM-3.3/NOPB

Part No LM2936MM-3.3/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 3.3V 50MA 8VSSOP
Datasheet
LM2936MM-3.3/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 40V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 0.2V @ 50mA
Output Current 50mA
Operating Supply Current 15μA to 2.5mA
PSRR 60dB (120Hz)
Control Protection Features Over Temperature, Reverse Polarity, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 0.2V @ 50mA
Mounting SMD (SMT)
Case / Package 8-VSSOP
Win Source Part Number 142999-LM2936MM-3.3/NOPB
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM2936MM-3.3/NOPB CAD Model

Description

The LM2936MM-3.3/NOPB is a high-performance, ultra-low quiescent current voltage regulator from Texas Instruments, a leading global semiconductor company.

  • Output Voltage: 3.3V (fixed)
  • Output Current: Up to 50mA
  • Dropout Voltage: Low
  • Quiescent Current: Very low, 15µA @ 100µA of load and 15mA @ full load
  • Line and Load Regulation: Built-in system to prevent issues
  • Protection: Thermal shutdown and current limit features, reverse battery protection
  • Package: 8-Pin VSSOP
  • Compliance: Fully RoHS compliant and lead-free
