LMH6722SD/NOPB High-Speed Operational Amplifier

The LMH6722SD/NOPB from Texas Instruments is a versatile, high-speed operational amplifier designed for a broad range of applications. This device is part of the PowerWise® family, which emphasizes energy-efficient solutions without compromising on performance. The LMH6722SD/NOPB offers an optimal balance between speed, power consumption, and noise performance, making it an excellent choice for video, communication, and test instrumentation systems.

Key Features

• Wide Bandwidth: The LMH6722SD/NOPB boasts a high bandwidth of 200 MHz when configured with a gain of +2, providing fast response times suitable for high-frequency signal processing.
• High Output Current: With the ability to deliver an output current of up to 85 mA, this operational amplifier can drive a wide range of loads, including capacitive loads commonly found in modern circuits.
• Low Distortion: The device features exceptionally low harmonic distortion, which is crucial for maintaining signal fidelity in audio and video applications.
• Slew Rate: A high slew rate of 1600 V/µs ensures that the LMH6722SD/NOPB can handle rapid changes in input signals without distortion, making it ideal for high-speed data acquisition systems.
• Single Supply Operation: The operational amplifier can be powered by a single supply voltage ranging from +2.7V to +11V, or dual supplies of ±1.35V to ±5.5V, providing flexibility in various circuit designs.

Applications

• High-Definition Video Processing
• Communication Infrastructure
• Active Filters
• Test and Measurement Equipment
• Professional Audio Equipment

With its low input noise density of 2.7 nV/√Hz and a total harmonic distortion plus noise (THD+N) of -75 dBc at 20 MHz, the LMH6722SD/NOPB ensures clean and precise signal amplification. The device is offered in a small-outline package, specifically an 8-pin WSON, which is suitable for space-constrained applications.

As a lead-free and RoHS-compliant component, the LMH6722SD/NOPB adheres to environmental standards, making it a responsible choice for both commercial and industrial applications. Texas Instruments' commitment to quality and reliability is evident in this high-performance operational amplifier, which is designed to meet the rigorous demands of modern electronic systems.
