The SN74AHC126PW from Texas Instruments is a high-performance, quadruple bus buffer gate featuring four independent line drivers with 3-state outputs. Designed to operate from 2 V to 5.5 V, this device is optimized for use in a wide range of voltage applications, making it suitable for interfacing with both 3.3 V and 5 V systems. Each buffer has a separate output-enable (OE) input that, when high, puts the respective output into a high-impedance state, thus allowing for bus-oriented applications.

Key Features

• Logic Family: AHC
• Logic Type: Quadruple Bus Buffer Gate with 3-State Outputs
• Supply Voltage Range: 2 V to 5.5 V
• Operating Temperature Range: -40°C to 85°C
• Package Type: TSSOP (Thin Shrink Small Outline Package)
• Pin Count: 14
• Propagation Delay Time: Fast propagation delays with balanced rise and fall times
• Output Current: High-drive outputs (-8 mA I_OH, 8 mA I_OL)

Applications

The SN74AHC126PW is ideal for a variety of applications where buffer gates are required, including:

• Bus driving
• Memory address driving
• Line driving
• Logic level shifting

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability, and the SN74AHC126PW is no exception. This device is manufactured using the company's advanced semiconductor processes, ensuring high performance and reliability across a wide range of environmental conditions.

Environmental Information

The SN74AHC126PW is RoHS compliant and is available in a lead-free package. Texas Instruments is dedicated to providing environmentally friendly solutions that meet the demands of modern electronic design and manufacturing.
