SN74AUP1G125DRLR Single Bus Buffer Gate by Texas Instruments

The SN74AUP1G125DRLR is a high-performance, single bus buffer gate with a 3-state output from Texas Instruments, designed to operate with a power supply range of 0.8V to 3.6V. This integrated circuit is part of the advanced ultra-low-power (AUP) family, which offers devices that combine low static and dynamic power consumption with high speed and high output drive.

Key Features:

• Low Power Consumption: The device boasts ultra-low power consumption, making it an ideal choice for power-sensitive applications.
• Wide Voltage Range: The SN74AUP1G125DRLR operates over a broad voltage range, accommodating various levels of signal amplitude and enabling it to be used in multi-voltage systems.
• High Drive: Despite its low power usage, the device provides a high output drive capability, ensuring strong signal transmission even over longer distances.
• 3-State Output: The 3-state output allows for connection to a bus-structured system, making it possible to share signal paths and reduce the need for additional lines.
• ESD Protection: Enhanced electrostatic discharge (ESD) protection is integrated into the design, safeguarding the device against sudden voltage spikes.

Applications:

The SN74AUP1G125DRLR is versatile in its applications, suitable for use in:

• Mobile Phones
• PDAs
• Portable Media Players
• Notebooks and Laptops
• Portable Medical Equipment
• And other battery-operated devices where power efficiency is critical.

Technical Specifications:

• Logic Family: AUP
• Logic Type: Buffer/Line Driver
• Number of Channels: 1
• Output Type: 3-State
• Package: SOT-5X3
• Mounting Type: Surface Mount

As a product of Texas Instruments, the SN74AUP1G125DRLR is backed by a reputation for quality and reliability in the semiconductor industry. It is a suitable component for designers looking to optimize their systems for both power efficiency and performance.
