SN74HC00N Real Image SN74HC00N Real Image
Same model may have multiple batches, images only for reference.
SN74HC00N Real Image SN74HC00N Real Image
SN74HC00N Real Image SN74HC00N Real Image
Same model may have multiple batches, images only for reference.

SN74HC00N

Part No SN74HC00N
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE NAND 4CH 2-INP 14-SO
Datasheet
SN74HC00N Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type NAND Gate
Number of Circuits 4
Number of Inputs 2
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 5.2mA, 5.2mA
Logic Level - Low 0.5 V to 1.8 V
Logic Level - High 1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL 15ns @ 6V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOP
Dimension 14-SOIC (0.209", 5.30mm Width)
Win Source Part Number 006786-SN74HC00N
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Microwave
Ultra Librarian 3D Model Ultra Librarian SN74HC00N CAD Model

Description

The SN74HC00N is a high-performance, advanced chip manufactured by Texas Instruments, a renowned global semiconductor company.

  • Series: 74HC
  • Type: High-speed CMOS logic quad 2-input NAND gate
  • Operating Voltage Range: 2V to 6V
  • Package: 14-pin DIP
  • Operating Temperature Range: -40°C to 85°C
  • Quiescent Current: 20µA @ 6V (maximum)
  • Noise Immunity: 1V @ VCC = 5V
  • Propagation Delay Time: 8ns @ VCC = 5V, CL = 15pF
  • Fan-Out: 10 LSTTL loads
  • Compliance: RoHS compliant
