Overview of Texas Instruments TLV1117LV15DCYR

The TLV1117LV15DCYR is a high-performance, low-dropout linear regulator (LDO) designed and manufactured by Texas Instruments (TI), a leader in semiconductor solutions. This LDO is specifically engineered to deliver a fixed output voltage of 1.5V with an input voltage range from 2.7V to 10V, making it an optimal choice for a wide array of electronic applications requiring a stable and precise voltage source.

Key Features

• Low Dropout: The TLV1117LV15DCYR boasts a low dropout voltage, ensuring efficient operation even when the input voltage is close to the output voltage, thus maximizing battery life in portable applications.
• High Output Current: Capable of delivering up to 800mA of output current, this LDO can power a range of components, from simple ICs to more demanding processors and digital circuits.
• Thermal and Overcurrent Protection: The device includes built-in thermal shutdown and overcurrent protection features, safeguarding your electronic designs against potential damage due to excessive temperature or load conditions.
• Stable with Low-ESR Capacitors: The TLV1117LV15DCYR is stable with ceramic capacitors, which have lower equivalent series resistance (ESR) than tantalum or aluminum electrolytic capacitors, thereby providing improved transient response and noise reduction.
• Adjustable Output Versions: While this specific model offers a fixed 1.5V output, the TLV1117 series also includes versions with an adjustable output voltage for increased design flexibility.

Applications

The TLV1117LV15DCYR is suitable for a variety of applications, including but not limited to:

• Consumer Electronics
• Portable and Battery-Powered Devices
• Microcontroller Power Supplies
• Peripheral Power Supplies
• Low-Power Handheld Instrumentation

Package and Quality

Encased in a compact SOT-223 package, the TLV1117LV15DCYR is designed for surface-mount technology (SMT) and occupies minimal board space. The device is RoHS compliant and adheres to TI's stringent quality standards, ensuring reliability and performance across various environmental conditions.

With its combination of features, the TLV1117LV15DCYR from Texas Instruments represents a robust power management solution for designers looking to enhance the efficiency and longevity of their electronic products.
