TLV2474AIPWPR: High-Performance, 16-V Rail-to-Rail Output Operational Amplifier

The TLV2474AIPWPR from Texas Instruments is a state-of-the-art operational amplifier that combines a wealth of features to deliver outstanding performance for a wide range of applications. This op-amp is part of the TLV247x family, which is known for its low-power consumption and high-speed operation, making it an ideal choice for battery-powered and portable devices.

Key Features

• High-Speed Performance: With a 2.8-MHz bandwidth and a 6.4-V/μs slew rate, the TLV2474AIPWPR ensures swift and accurate signal processing, which is crucial for applications requiring fast response times.
• Rail-to-Rail Output: The rail-to-rail output capability allows for maximum dynamic range, making this op-amp highly effective in single-supply operations and in systems where output swing to the power supply rails is necessary.
• Low-Power Operation: Despite its high-speed characteristics, the TLV2474AIPWPR maintains low power consumption with a supply current of just 600 μA per channel, thereby extending battery life in portable applications.
• Wide Supply Voltage Range: This operational amplifier can operate from a supply voltage range of 2.7 V to 16 V, accommodating a variety of power sources and ensuring versatility in different circuit designs.
• Micropower Shutdown Mode: An additional feature is its micropower shutdown mode, which reduces the supply current to 0.3 μA/channel, further conserving power when the amplifier is not in active use.

Applications

The TLV2474AIPWPR is well-suited for a multitude of applications, including:

• Portable and battery-operated devices
• Analog filters
• Data acquisition systems
• Medical instrumentation
• Audio and video processing
• Sensor signal conditioning

With its robust design, the TLV2474AIPWPR is packaged in a 14-pin TSSOP (Thin Shrink Small Outline Package), offering a compact footprint for space-constrained applications. Its extended temperature range and the reliability of Texas Instruments' manufacturing also make it a trusted choice for industrial and commercial products.

Whether you're designing a sophisticated audio interface, a precise sensor module, or a power-sensitive portable device, the TLV2474AIPWPR operational amplifier is engineered to deliver high performance with minimal power draw.
