Overview of Texas Instruments TPS23841PJD

The TPS23841PJD from Texas Instruments is a robust, feature-rich Power over Ethernet (PoE) controller designed for use in a range of applications that require the delivery of power over Ethernet cabling. This integrated circuit is part of TI's Power Management portfolio and is specifically tailored for Power Sourcing Equipment (PSE) applications.

Key Features

• IEEE 802.3at Compliant: The TPS23841PJD adheres to the IEEE 802.3at standard, ensuring compatibility with the latest PoE+ devices and systems, providing up to 30 watts of power per port.
• Quad-Port Capability: This controller can manage up to four PoE ports, making it an efficient choice for multi-port PSEs such as Ethernet switches and midspans.
• Advanced Power Management: It features programmable power limiting, auto-classification, and power-good reporting, which helps in efficient power allocation and management across the network.
• High Reliability: Built-in fault protection and thermal management ensure reliable operation under various conditions, protecting both the PSE and the powered devices.
• Flexible Power Supply Options: The TPS23841PJD is designed to work with a wide range of power supply voltages, accommodating different system requirements.

Applications

The versatility of the TPS23841PJD makes it suitable for a variety of applications, including:

• Enterprise Ethernet Switches
• Wireless Access Points
• IP Surveillance Cameras
• VoIP Phones
• Networked Lighting Systems

Technical Specifications

The TPS23841PJD operates over an industrial temperature range and comes in a PowerPAD™ 80-pin HTQFP package. It integrates multiple features that facilitate system design, such as I<sub>cut and I<sub>limit programming, a wide MOSFET voltage range, and programmable power-up sequencing.

Conclusion

For designers and engineers looking to implement Power over Ethernet solutions, the TPS23841PJD from Texas Instruments offers a reliable and flexible option that simplifies the development of PSEs. Its adherence to industry standards, combined with advanced power management features, ensures that it can meet the needs of modern, power-sensitive networks.
