TPS65150EVM-697 Evaluation Module

The TPS65150EVM-697 is a fully assembled and tested circuit for evaluating the TPS65150, a compact, integrated power management IC designed by Texas Instruments. This evaluation module (EVM) provides a comprehensive platform for testing the capabilities of the TPS65150 chip in various applications, particularly those requiring multiple output voltages, such as LCD bias supplies in TVs, monitors, and notebook panels.

The TPS65150 IC offers a versatile solution for generating both positive and negative output voltages with excellent power efficiency and minimal external components. It integrates one boost converter and two charge pump controllers to provide a complete power supply solution. The EVM includes adjustable output voltage settings, enabling users to tailor the output for their specific needs. The TPS65150EVM-697 is equipped with a range of features that make it an ideal tool for design engineers and professionals in the electronics industry.

Key Features:

• Support for a wide input voltage range from 1.8V to 6V.
• Adjustable positive output voltage up to 15V for the boost converter.
• Negative output voltage down to -15V, generated by the inverting charge pump.
• High efficiency and low quiescent current to enhance battery life in portable applications.
• Integrated thermal shutdown and over-current protection features for improved safety and reliability.
• Small package size and minimal external components required for a compact power solution.

The EVM includes test points and jumper settings that allow for easy evaluation of the TPS65150's performance characteristics. Comprehensive documentation and support are provided by Texas Instruments to facilitate rapid development and integration of the TPS65150 into various applications.

Whether for prototyping or for educational purposes, the TPS65150EVM-697 offers an excellent platform for exploring the functionality and performance of the TPS65150 power management IC.
