TPS7A8400RGRT

Part No TPS7A8400RGRT
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO ADJ/PROG 3A
Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Adjustable/Programmable
Number of Regulators 1
Maximum Input Voltage 6.5V
Nominal Output Voltage (Min/Fixed) 0.8V
Maximum Output Voltage 5V
Dropout Voltage-Max 0.34V @ 3A
Output Current 3A
Operating Supply Current 4mA to 5.5mA
PSRR 42dB to 25dB (10kHz to 500kHz)
Control Features Enable, Power Good, Soft Start
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 20-VQFN (3.5x3.5)
Win Source Part Number 1113572-TPS7A8400RGRT
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Power Management, Industrial, Test & Measurement
Ultra Librarian 3D Model Ultra Librarian TPS7A8400RGRT CAD Model

Description

Product Overview: TPS7A8400RGRT by Texas Instruments

The TPS7A8400RGRT from Texas Instruments is a state-of-the-art low-dropout regulator (LDO) designed for applications that require low noise, high precision, and high efficiency. This advanced LDO is capable of delivering a continuous output current of up to 1A and has an input voltage range of 1.4V to 6.5V, which makes it highly versatile for various electronic devices and systems.

Key Features

  • Low Dropout Voltage: The TPS7A8400RGRT boasts a low dropout voltage, ensuring efficient operation even when the input voltage is close to the output voltage, thereby maximizing battery life in portable applications.
  • High Output Accuracy: With an output voltage accuracy of 1%, the device ensures precise voltage delivery, critical for sensitive analog circuits and precision applications.
  • Ultra-Low Noise: The LDO features an ultra-low noise output, which is essential for RF and audio applications where noise can significantly affect performance.
  • Power Supply Rejection Ratio (PSRR): With excellent PSRR characteristics, the TPS7A8400RGRT minimizes the effect of supply voltage variations on the output voltage, making it ideal for post-regulation applications.
  • Thermal Shutdown and Overcurrent Protection: Built-in safety features protect the device and the system from damage due to excessive heat and current conditions.
  • Adjustable Output Voltage: The output voltage is adjustable from 0.8V to 5.0V, allowing for flexible use in a wide range of applications.

Applications

The TPS7A8400RGRT is suitable for a diverse set of applications, including:

  • High-performance analog circuits
  • Precision data converters
  • Wireless communication systems
  • Audio applications
  • Medical equipment
  • Portable and battery-powered devices

Its compact QFN-20 package makes it easy to integrate into space-constrained designs while providing excellent thermal performance. The TPS7A8400RGRT is a reliable choice for designers looking for an LDO that combines high performance with versatility.

For detailed specifications, application notes, and design resources, visit the Texas Instruments website or consult the TPS7A8400RGRT datasheet.
