ULN2003APWR by Texas Instruments

The ULN2003APWR is a high-voltage, high-current Darlington transistor array designed by Texas Instruments. This integrated circuit is specifically engineered to interface between low-level logic circuitry and multiple peripheral power loads typically found in drivers for relays, lamps, and stepper motors. With its robust design, the ULN2003APWR is an essential component in a wide range of applications, including home appliances, office machines, and industrial automation systems.

Key Features:

• Seven Darlington Arrays: Each array comprises a Darlington pair with high-voltage outputs and common-cathode clamp diodes for inductive transient suppression.
• High Voltage Outputs: The outputs can sustain up to 50V, making the device suitable for interfacing with higher voltage levels.
• High Current Capability: Capable of delivering output currents up to 500mA for each channel, with a collective current limit of up to 2.5A for all channels combined.
• Wide Operating Voltage: The device operates efficiently across a voltage range of 5V to 50V, providing versatility in various circuit configurations.
• Input Compatibility: Compatible with various logic levels, it can be directly connected to TTL and 5V CMOS devices.
• Thermal Shutdown: Features an internal thermal shutdown mechanism to protect the device from overheating and potential damage.
• Package: Offered in a TSSOP-16 (Thin Shrink Small Outline Package) that is designed for space-saving on PCBs.

Applications:

• Relay Drivers
• Stepper and DC Brushed Motor Drivers
• Lamp Drivers
• LED Displays and Signage
• Line Drivers
• Logic Buffers

The ULN2003APWR is an optimal solution for designers looking to drive multiple peripheral devices with high efficiency and reliability. Its combination of high-voltage and high-current capabilities along with its protective features ensures that it can handle rigorous industrial demands and provide stable performance in a compact footprint.
