The TC74VHC11FT is a triple 3-input AND gate from Toshiba. It belongs to the VHC (Very High-Speed CMOS) family, offering high-speed operation and low power consumption. It is designed for general-purpose logic applications requiring AND operations. Its optimized design ensures minimal propagation delay and high noise immunity, making it suitable for various digital systems.

Applications

• Data Processing: Used in data processing circuits for AND operations.
• Signal Processing: Employed in signal processing systems to implement logical AND functions.
• Control Systems: Found in control logic for industrial and consumer electronics.
• Address Decoding: Utilized in memory systems for address decoding.
• Logic Gates: General-purpose logic gate for digital circuits.

Features

• High-Speed Operation: Offers a typical propagation delay of 4.1 ns at VCC = 5V.
• Low Power Consumption: Features low quiescent current, minimizing power dissipation.
• Wide Operating Voltage Range: Operates from 2V to 5.5V.
• High Noise Immunity: Provides excellent noise margins for reliable operation.
• Triple 3-Input AND Gate: Contains three independent 3-input AND gates in a single package.

Benefits

• Improved System Performance: High-speed operation enables faster processing and response times.
• Reduced Power Consumption: Low power consumption contributes to energy efficiency and longer battery life.
• Flexible Operation: Wide operating voltage range allows for use in various systems.
• Reliable Performance: High noise immunity ensures stable operation in noisy environments.
• Compact Design: Small package size facilitates space-saving designs.

Additional Details

The TC74VHC11FT is available in a TSSOP (Thin Shrink Small Outline Package), making it suitable for high-density PCB designs. It operates over a temperature range of -40°C to +85°C. The input pins are equipped with protection diodes to guard against electrostatic discharge (ESD). This component is lead-free and RoHS compliant.
