The TLP2395(TPL,E(O is a high-speed photocoupler from Toshiba Semiconductor and Storage. It is designed for high-speed logic interface applications and features a high common-mode transient immunity. This photocoupler consists of a GaAlAs light-emitting diode (LED) optically coupled to a high-gain, high-speed photodetector IC chip.

Applications:

• High-speed logic interface
• Programmable logic controllers (PLCs)
• Inverter control
• Switching power supplies
• Measurement and control equipment

Features:

• High common-mode transient immunity: ±20 kV/μs (typ.)
• High-speed: 10 Mbps (typ.)
• Low input current: IF = 5 mA (max.)
• Wide supply voltage: 2.7 V to 5.5 V
• Operating temperature: -40 to 105°C
• Small SO6 package
• Safety standard: UL recognized: UL1577, File No.E67349
• Safety standard: cUL recognized: CSA Component Acceptance Service No.5A, File No.E67349
• Safety standard: EN/IEC60747-5-5 VDE Certificate No.40050312

Benefits:

• Improved system reliability: The high common-mode transient immunity prevents erroneous data transmission in noisy environments.
• Increased system performance: The high-speed operation allows for faster data transfer rates.
• Reduced power consumption: The low input current reduces the power required to drive the photocoupler.
• Simplified system design: The wide supply voltage range simplifies the power supply requirements.
• Compact size: The small SO6 package saves board space.
• Meets safety standards: UL, cUL, and EN/IEC certifications ensure safety compliance.

Additional Details:

The TLP2395(TPL,E(O uses a sophisticated internal shield to provide high common-mode transient immunity, making it suitable for use in harsh industrial environments. The device's open-collector output allows for flexible interfacing with various logic families. The TLP2395 is available in a SO6 surface-mount package, which simplifies assembly and reduces board space.

The device is compliant with RoHS directive, making it an environmentally friendly option.
