IRF9530PBF Vishay IRF9530PBF Real Image IRF9530PBF real image
Same model may have multiple batches, images only for reference.
IRF9530PBF Vishay IRF9530PBF Real Image IRF9530PBF real image
IRF9530PBF Vishay IRF9530PBF Real Image IRF9530PBF real image
Same model may have multiple batches, images only for reference.

IRF9530PBF

Part No IRF9530PBF
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 100V 12A TO-220AB
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 12A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 38nC @ 10V
Max Input Capacitance 860pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 88W (Tc)
Maximum Rds On at Id,Vgs 300 mOhm @ 7.2A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 017559-IRF9530PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IRF9530
Introduction Date March 27, 2007
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian IRF9530PBF CAD Model

Description

The Vishay IRF9530PBF is a P-channel MOSFET transistor with a drain-source breakdown voltage of 100V and a continuous drain current of 12A (Tc).

  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Maximum Gate Charge: 38nC @ 10V
  • Maximum Rds On @ Id,Vgs: 300 mOhm @ 7.2A, 10V
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Mounting: through hole
  • Case/Package: TO-220AB
  • Dimension: TO-220-3
  • Temperature Range: -55°C to 175°C (TJ)
  • Halogen-Free: compliant
  • Popularity: popular in the market
