IRFP264PBF Real Image IRFP264PBF Real Image
Same model may have multiple batches, images only for reference.
IRFP264PBF Real Image IRFP264PBF Real Image
IRFP264PBF Real Image IRFP264PBF Real Image
Same model may have multiple batches, images only for reference.

IRFP264PBF

Part No IRFP264PBF
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 250V 38A 3-Pin(3+Tab) TO-247AC / MOSFET N-CH 250V 38A TO-247AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 250V
Continuous Drain Current at 25°C 38A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 210nC @ 10V
Max Input Capacitance 5400pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 280W (Tc)
Maximum Rds On at Id,Vgs 75 mOhm @ 23A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-247-3
Dimension TO-247-3
Win Source Part Number 089862-IRFP264PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name IRFP264
Introduction Date March 27, 2007
ECCN EAR99
Country of Origin China, Israel, Mexico
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian IRFP264PBF CAD Model

Description

The Vishay IRFP264PBF is an N-Channel MOSFET transistor that is widely used in various electronic applications.

  • Power Dissipation: 280W (Tc)
  • Continuous Drain Current: 38A (Tc)
  • Supply and Demand Status: Sufficient
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Rds On at Id,Vgs: 75 mOhm @ 23A, 10V
