SI1303DL-T1-E3 Real Image SI1303DL-T1-E3 label picture
Same model may have multiple batches, images only for reference.
SI1303DL-T1-E3 Real Image SI1303DL-T1-E3 label picture
SI1303DL-T1-E3 Real Image SI1303DL-T1-E3 label picture
Same model may have multiple batches, images only for reference.

SI1303DL-T1-E3

Part No SI1303DL-T1-E3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 20V 670MA SOT323-3
Datasheet
SI1303DL-T1-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 670mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
Gate-Source Threshold Voltage 1.4V @ 250μA
Max Gate Charge 2.2nC @ 4.5V
Maximum Gate-Source Voltage ±12V
Power Dissipation (Max) 290mW (Ta)
Maximum Rds On at Id,Vgs 430 mOhm @ 1A, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SC-70-3
Dimension SC-70, SOT-323
Win Source Part Number 028341-SI1303DL-T1-E3
Family Name Si1303DL
Introduction Date August 12, 2009
ECCN EAR99
Country of Origin China
Halogen Free Not Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SI1303DL-T1-E3 CAD Model

Description

The Vishay MOSFET has a Win Source Part Number of 028341-SI1303DL-T1-E3 and is packaged in a reel - TR.

  • Mounting: SMD (SMT)
  • Polarity: P-Channel
  • Power Dissipation: 290mW (Ta)
  • Category: Discrete Semiconductor Products
  • Drive Voltage: 2.5V, 4.5V
  • Status: Obsolete (EOL)
  • Operating Temperature: -55°C to 150°C (TJ)
  • Case/Package: SC-70-3
  • Dimension: SC-70, SOT-323
  • Drain-Source Breakdown Voltage: 20V
  • Continuous Drain Current @ 25°C: 670mA (Ta)
  • Gate-Source Threshold Voltage: 1.4V @ 250μA
  • Maximum Gate Charge: 2.2nC @ 4.5V
  • Maximum Rds On @ Id,Vgs: 430 mOhm @ 1A, 4.5V
  • Alternative Parts: RTF010P02TR, RTF010P02, and FDY102PZ
  • Introduction Date: August 12, 2009
  • ECCN: EAR99
  • Country of Origin: China
  • Estimated EOL Date: obsolete
  • Halogen-Free: No
  • Usage: Common-used part
  • Popularity: High
  • Fake Products Threat: 44%
  • Supply and Demand: Sufficient
