Same model may have multiple batches, images only for reference.

SQJB60EP-T1_GE3

Name: SQJB60EP-T1_GE3
Brand: Vishay
SKU: 1278518
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

Part No	SQJB60EP-T1_GE3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Datasheet	SQJB60EP-T1_GE3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Arrays
Mfr	Vishay Siliconix
Series	Automotive, AEC-Q101, TrenchFET®
Package	Tape & Reel
FET Type	2 N-Channel (Dual)
FET Feature	Standard
Drain to Source Voltage (Vdss)	60V
Current - Continuous Drain (Id) @ 25°C	30A (Tc)
Rds On (Max) @ Id, Vgs	12mOhm @ 10A, 10V
Vgs(th) (Max) @ Id	2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	30nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds	1600pF @ 25V
Power - Max	48W
Temperature Range - Operating	-55°C ~ 175°C (TJ)
Mounting	SMD (SMT)
Package / Case	PowerPAK® SO-8 Dual
Supplier Device Package	PowerPAK® SO-8 Dual
Base Product Number	SQJB60
Other Names	SQJB60EP-T1_GE3CT,SQJB60EP-T1_GE3DKR,SQJB60EP-T1_GE3TR
Standard Package	3,000
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8541.29.0095
Win Source Part Number	1278518-SQJB60EP-T1_GE3
Ultra Librarian 3D Model	Ultra Librarian SQJB60EP-T1_GE3 CAD Model

Alternative Products

Description

The Vishay Siliconix PowerPAK® SO-8 Dual MOSFET is a high-performance semiconductor device that is perfect for use in various applications.

FET: 2 N-Channel (Dual)
Drain to Source Voltage (Vdss): 60V
Continuous Drain Current (Id): 30A (Tc) @ 25°C
Rds On (Max) @ Id, Vgs: 12mOhm @ 10A, 10V
Gate Charge (Qg) (Max) @ Vgs: 30nC @ 10V
AEC-Q101 Compliant: Suitable for automotive applications
Package: PowerPAK® SO-8 Dual
Standard Package: 3,000
