Same model may have multiple batches, images only for reference.

SUM110P04-05-E3

Name: SUM110P04-05-E3
Brand: Vishay
SKU: 520993
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SUM110P04-05-E3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 40V 110A D2PAK
Datasheet	SUM110P04-05-E3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	40V
Continuous Drain Current at 25°C	110A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4V @ 250μA
Max Gate Charge	280nC @ 10V
Max Input Capacitance	11300pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	15W (Ta), 375W (Tc)
Maximum Rds On at Id,Vgs	5 mOhm @ 20A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	TO-263 (D2Pak)
Dimension	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number	1104113-SUM110P04-05-E3
Popularity	Medium
Supply and Demand Status	Limited
Application Field	Used in Power Management
Ultra Librarian 3D Model	Ultra Librarian SUM110P04-05-E3 CAD Model

Alternative Products

Description

The Vishay SUM110P04-05-E3 is a P-channel MOSFET used in discrete semiconductor products.

Power Dissipation: 15W (Ta) and 375W (Tc)
Drain-Source Breakdown Voltage: 40V
Continuous Drain Current: 110A @ 25°C
Gate-Source Threshold Voltage: 4V @ 250μA
Package: TO-263 (D2Pak)
ECCN: EAR99
Supply and Demand Status: limited
