Same model may have multiple batches, images only for reference.
744878101 Real Image
Same model may have multiple batches, images only for reference.

744878101

Part No 744878101
Manufacturer Wurth Electronics Inc
Catalog Arrays, Signal Transformers
Description INDUCT ARRAY 2 COIL 100UH SMD / Shielded 2 Coil Inductor Array 400 µH Inductance - Connected in Series 100 µH Inductance - Connected in Parallel 1.73Ohm Max DC Resistance (DCR) - Parallel 300 mA Nonstandard
Datasheet
744878101 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Arrays, Signal Transformers
Manufacturer Würth Elektronik
Packaging Reel - TR
Number of Coils 2
Inductance - Connected In Parallel 100 µH
Inductance - Connected In Series 400 µH
Tolerance ±20%
Current Rating - Parallel 300 mA
Current Rating - Series 150 mA
Current Saturation - Parallel 700 mA
Current Saturation - Series 350 mA
DC Resistance (DCR) - Parallel 1.73Ohm Max
Shielding Shielded
Temperature Range - Operating -40°C ~ 125°C
Mounting Surface Mount
Case / Package Nonstandard
Size / Dimension 0.287" L x 0.287" W (7.30mm x 7.30mm)
Height 0.157" (4.00mm)
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Other Part Number 732-2307-2,732-2307-1,732-2307-6
Standard Package 1,000
Win Source Part Number 1327551-744878101
Ultra Librarian 3D Model Ultra Librarian 744878101 CAD Model

Description

The Würth Elektronik 1327551-744878101 is a shielded inductor array that measures 0.287 inches in length and width.

  • Shielding: shielded
  • Size: 0.287 inches (length and width)
  • Height: 0.157 inches
  • Number of Coils: two
  • Inductance (Series): 400 µH
  • Inductance (Parallel): 100 µH
  • Current Rating (Series): 150 mA
  • Current Rating (Parallel): 300 mA
  • Current Saturation (Series): 350 mA
  • Current Saturation (Parallel): 700 mA
  • DC Resistance (DCR) (Parallel): 1.73 Ohm max
  • Operating Temperature: -40°C to 125°C
  • Case/Package: nonstandard
  • ROHS3 Compliant: true
