UDT14A05L03

Name: UDT14A05L03
Brand: Yageo
SKU: 1102111
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	UDT14A05L03
Manufacturer	Yageo
Catalog	TVS - Diodes
Description	TVS ARRAY ESD, SOT-143, 5V 25V,
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr	YAGEO
Series	UDT14A05L03
Package	Tape & Reel
Product Status	Active
Type	Zener
Unidirectional Channels	2
Voltage - Reverse Standoff (Typ)	5V (Max)
Voltage - Breakdown (Min)	6V
Voltage - Clamping (Max) @ Ipp	25V
Current - Peak Pulse (10/1000µs)	12A (8/20µs)
Power Line Protection	Yes
Applications	Ethernet, USB
Capacitance @ Frequency	1.5pF @ 1MHz
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	TO-253-4, TO-253AA
Supplier Device Package	SOT-143
Standard Package	3,000 pcs
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8541.10.0080
Win Source Part Number	1102111-UDT14A05L03
Ultra Librarian 3D Model	Ultra Librarian UDT14A05L03 CAD Model

Alternative Products

Description

The 1102111-UDT14A05L03 is a TVS diode designed for circuit protection in Ethernet and USB applications.

Series: YAGEO's UDT14A05L03
Package: tape & reel
Voltage Reverse Standoff: 5V (Max)
Voltage Breakdown: 6V
Clamping Voltage: 25V (Max)
Component: Surface mount
Package Size: TO-253-4, TO-253AA (SOT-143)
Channels: Two unidirectional
Power Line Protection: Yes
Capacitance: 1.5pF @ 1MHz
Peak Pulse Current: 12A (10/1000µs)
Operating Temperature Range: -55°C to 150°C
REACH Regulations: Unaffected
Manufacturer: YAGEO
