AD7793BRUZ-REEL7 - Analog Devices Inc.

The AD7793BRUZ-REEL7 is a high-performance, low-power, 24-bit sigma-delta (Σ-Δ) Analog-to-Digital Converter (ADC) from Analog Devices Inc., a renowned leader in precision signal processing technology. Designed to provide precise data acquisition in instrumentation and control systems, this ADC is an ideal choice for applications requiring high resolution and low noise, such as industrial process control, smart transmitters, and medical instrumentation.

This ADC features a low-noise programmable gain array, and a precision low-noise, low-drift internal band-gap reference, making it highly suitable for measuring low-level signals. The AD7793BRUZ-REEL7 offers a high degree of flexibility with its 3 fully differential or 4 pseudo-differential analog input channels, and its ability to interface with a wide variety of sensors directly.

With its onboard low-noise amplifier, the device is capable of handling input signals from sensors with a wide dynamic range, making it a versatile solution for diverse measurement scenarios. The AD7793BRUZ-REEL7 operates with a power supply ranging from 2.7V to 5.25V and features a low current consumption of 400 μA typical, which is beneficial for power-sensitive applications.

The device also includes a number of digital features that enhance its functionality, such as a digital filter for data smoothing and synchronization, and a serial interface that is SPI-compatible, allowing for easy communication with microcontrollers and digital systems. Additionally, the ADC comes in a compact TSSOP-16 package, making it space-efficient for design in tight PCB layouts.

Overall, the AD7793BRUZ-REEL7 from Analog Devices Inc. is a robust and reliable ADC solution that delivers high-accuracy data conversion with the ease of integration into various electronic systems, ensuring precise and consistent performance for advanced measurement and control applications.
