AD8227ARMZ-R7

Part No AD8227ARMZ-R7
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description INST Amp Single R-R O/P ±18V/36V 8-Pin MSOP T/R / IC OPAMP INSTR 250KHZ RRO 8MSOP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Active
Amplifier Type Instrumentation
Number of Circuits 1
Output Type Rail-to-Rail
Slew Rate 0.8 V/μs
-3db Bandwidth 250kHz
Current - Input Bias 20nA
Voltage - Input Offset 200μV
Operating Supply Current 350μA
Channel Output Current 13mA
Supply Voltage - Operating 2.2 V to 36 V, ±1.5 V to 18 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-MSOP
Win Source Part Number 120522-AD8227ARMZ-R7
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name AD8227
Introduction Date May 05, 2009
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian AD8227ARMZ-R7 CAD Model

Description

Product Overview: AD8227ARMZ-R7

The AD8227ARMZ-R7 from Analog Devices Inc. is a high-performance, single-supply instrumentation amplifier that is designed to offer a perfect blend of ease of use and versatility. Packaged in a compact MSOP-8 format, this amplifier is suitable for a wide range of applications, including medical instrumentation, industrial process controls, and battery-powered devices.

Key Features

  • Rail-to-Rail Output: The AD8227ARMZ-R7 features a rail-to-rail output swing, which allows for maximum dynamic range, especially beneficial when operating at lower supply voltages.
  • Single-Supply Operation: With a supply range from 1.8 V to 5.5 V, this instrumentation amplifier can be used in systems where power efficiency and supply voltage are critical considerations.
  • High Common-Mode Rejection: A common-mode rejection ratio (CMRR) of 86 dB (min) at G = 1 ensures accurate measurements in the presence of noise and varying common-mode voltages.
  • Wide Gain Range: The device offers an adjustable gain set by a single external resistor, ranging from 1 to 1000, providing flexibility across different use cases.
  • Low Offset Voltage: The low input offset voltage of 250 µV max at G = 1 enables precision measurements with minimal error.

Applications

The AD8227ARMZ-R7 is designed to be a versatile component suitable for a variety of applications. Its precision and low power consumption make it an ideal choice for:

  • Portable medical devices
  • Industrial process controls
  • Strain gages and pressure sensors
  • 4 mA to 20 mA loop-powered systems
  • Data acquisition systems

Product Specifications

Parameter Value
Part Number AD8227ARMZ-R7
Manufacturer Analog Devices Inc.
Package/Case MSOP-8
Supply Voltage 1.8 V to 5.5 V
Operating Temperature -40°C to +125°C

With its robust design and high accuracy, the AD8227ARMZ-R7 is an excellent choice for engineers and designers looking for a reliable instrumentation amplifier for their next project.
