The ADG884BRMZ is a high-performance, dual single-pole/double-throw (SPDT) switch from Analog Devices Inc., designed for use in a wide range of applications, including data acquisition systems, communication systems, and audio and video signal routing. This versatile switch is well-suited for both analog and digital applications, providing a seamless interface for multiplexing and demultiplexing signals.

Key Features

• Low On-Resistance: The ADG884BRMZ boasts a low on-resistance of typically 0.4 ohms, ensuring minimal signal distortion and power loss through the switch.
• Wide Supply Range: It operates from a single 1.8 V to 5.5 V supply, making it compatible with a variety of logic levels and providing design flexibility across multiple platforms.
• High Current Carrying Capability: With a continuous current rating of up to 200 mA per channel, this switch can handle significant current without performance degradation.
• Low Power Consumption: The device features ultra-low power consumption, which is critical for battery-powered portable devices, thereby extending operational life.
• 3.3 V/5 V Logic Compatible: The inputs are compatible with both 3.3 V and 5 V logic, allowing for easy integration into mixed-voltage systems.
• Break-Before-Make Switching: This functionality ensures that one channel is disconnected before another is connected, preventing signal cross-talk and shorting.

Applications

• Audio and Video Switching
• Data Acquisition Systems
• Communication Systems
• Relay Replacement
• Test Equipment and Instrumentation

Package and Quality

The ADG884BRMZ comes in a compact 10-lead MSOP (Mini Small Outline Package) that is RoHS compliant and designed for space-constrained applications. Analog Devices Inc. ensures high-quality and reliability, making the ADG884BRMZ an excellent choice for critical applications where performance and dependability are paramount.

Ordering Information

To order or inquire about the ADG884BRMZ, visit the Analog Devices Inc. website or contact an authorized distributor. This product is available for immediate shipping, subject to market availability.
