The PCI9656-BA66BIG is a high-performance 32-bit PCI Local Bus Target/Master I/O Accelerator from Broadcom Limited. It provides a robust interface between a host processor and a wide array of peripheral devices connected to the PCI bus. Commonly used in PCI-based add-in cards and embedded systems, it's designed for applications requiring rapid data transfer and versatile I/O capabilities. The suffix 'BA66BIG' likely refers to specific package types, speed grades, or feature sets.

Applications

• High-Performance Networking Equipment
• Advanced Industrial Automation Systems
• Real-Time Data Processing Applications
• High-Resolution Imaging Systems
• Demanding Embedded Computing Platforms

Features

• 32-bit PCI interface
• Operates at 66 MHz PCI bus speed
• Supports PCI Target and Master modes
• Integrated DMA controller for optimized data transfer
• Flexible local bus interface for connecting various peripherals
• Interrupt generation and handling capabilities
• On-chip EEPROM interface for configuration storage
• Enhanced I/O performance

Benefits

• Simplified PCI interface implementation
• Reduced development time and costs
• Maximized system performance with efficient DMA
• Versatile I/O connectivity options
• Increased system reliability
• Easy configuration via EEPROM

Operating at a PCI bus speed of 66 MHz, the PCI9656-BA66BIG excels in applications requiring rapid data throughput. The integrated DMA controller optimizes data movement between the PCI bus and the local bus, improving overall system performance. The flexible local bus interface enables developers to connect a wide array of peripheral devices. The on-chip EEPROM simplifies configuration and system setup. This device provides a high-performance and versatile solution for applications requiring fast and reliable PCI bus connectivity, making it well-suited for demanding industrial and embedded environments.
