CYBL10462-56LQXI

Part No CYBL10462-56LQXI
Manufacturer Cypress Semiconductor Corp
Catalog RF Receivers
Description IC RF TXRX+MCU BLUETOOTH 56UFQFN  /  IC RF TxRx + MCU Bluetooth Bluetooth v4.1 2.4GHz 56-UFQFN Exposed Pad
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF/IF and RFID>RF Transceiver ICs
Mfr Cypress Semiconductor Corp
Package Tray
Product Status Obsolete
Type TxRx + MCU
RF Family/Standard Bluetooth
Protocol Bluetooth v4.1
Modulation GFSK
Frequency 2.4GHz
Data Rate (Max) 1Mbps
Power - Output 3dBm
Sensitivity -91dBm
Memory Size 128kB Flash, 8kB ROM, 16kB SRAM
Serial Interfaces I2C, I2S, SPI, UART
GPIO 36
Voltage - Supply 1.8V ~ 5.5V
Current - Receiving 16.4mA ~ 21.5mA
Current - Transmitting 12.5mA ~ 20mA
Temperature Range - Operating -40°C ~ 105°C
Mounting SMD (SMT)
Package / Case 56-UFQFN Exposed Pad
Supplier Device Package 56-QFN (7x7)
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
HTSUS 8542.39.0001
Other Names 428-3356,-CYBL10462-56LQXI,2266-CYBL10462-56LQXI,2015-CYBL10462-56LQXI,2156-CYBL10462-56LQXI,CYPCYPCYBL10462-56LQXI
Standard Package 260
Win Source Part Number 1006424-CYBL10462-56LQXI
Ultra Librarian 3D Model Ultra Librarian CYBL10462-56LQXI CAD Model

Description

The CYBL10462-56LQXI is an obsolete electronic component manufactured by Cypress Semiconductor Corp.

  • Type: TxRx + MCU RF transceiver IC
  • Frequency: 2.4GHz
  • Protocol: Bluetooth v4.1
  • Memory Size: 128kB Flash, 8kB ROM, and 16kB SRAM
  • Power Output: 3dBm
  • Sensitivity: -91dBm
  • Current Receiving: 16.4mA ~ 21.5mA
  • Current Transmitting: 12.5mA ~ 20mA
  • Voltage Supply: 1.8V ~ 5.5V
  • GPIO: 36
  • Package: 56-UFQFN Exposed Pad
  • Temperature Range: -40°C ~ 105°C
