The AZ1117CH-1.2TRG1 is a high-performance, low-dropout linear regulator designed by Diodes Incorporated, tailored for a wide range of applications. This robust voltage regulator offers a fixed output voltage of 1.2V, which is particularly suited for low voltage, high current operations in various electronic devices.

Key Features

• Stable Output: The device provides a stable 1.2V output voltage with an accuracy of ±1%, ensuring reliable operation for sensitive electronic circuits.
• High Current Capability: With an ability to deliver up to 1A of continuous output current, this regulator can support applications that require a significant power supply.
• Low Dropout Voltage: The AZ1117CH-1.2TRG1 exhibits a low dropout voltage, typically 1.1V at 800mA of load current, making it efficient for systems with a minimal difference between input and output voltage.
• Thermal Protection: It includes built-in thermal shutdown protection that safeguards the device and the overall system from the dangers of overheating.
• Current Limiting: A current limit feature is incorporated to prevent damage from overcurrent conditions, enhancing the safety and longevity of the regulator.

Applications

The AZ1117CH-1.2TRG1 is versatile and can be used in a variety of applications, including but not limited to:

• High-efficiency linear power supplies
• Battery chargers
• Post regulators for switching supplies
• Low voltage logic supplies
• Portable consumer electronics

Package and Quality

This component is offered in a compact SOT-223 package, which is ideal for space-constrained applications. The AZ1117CH-1.2TRG1 is provided in tape and reel packaging, facilitating efficient assembly during the manufacturing process. Diodes Incorporated ensures that this product meets high-quality standards, with rigorous testing and quality control measures in place.

Conclusion

In conclusion, the AZ1117CH-1.2TRG1 from Diodes Incorporated is a reliable and efficient solution for applications requiring a stable and robust power supply. Its combination of low dropout voltage, high current capability, and protective features make it an excellent choice for designers looking to optimize their power management systems.
