Diodes Incorporated DMP2240UW-7 P-Channel Enhancement Mode MOSFET

The DMP2240UW-7 from Diodes Incorporated is a high-performance P-Channel enhancement mode Field Effect Transistor (MOSFET) designed for power management applications. This efficient semiconductor device is specifically tailored to provide low on-resistance and a high blocking voltage, making it ideal for a wide range of applications, including load switch, power management, and battery protection circuits.

Constructed with advanced trench technology, the DMP2240UW-7 is housed in an ultra-small SOT-323 package, which is highly beneficial for space-constrained applications. The device features a drain-source voltage (V_DS) of -20V and a continuous drain current (I_D) of -3.9A at 25°C, ensuring robust performance for various electronic designs.

One of the key advantages of the DMP2240UW-7 is its low threshold voltage (V_GS(th)), which allows for operation at lower gate voltages, thus reducing power consumption. The low on-resistance (R_DS(on)) of just 70mΩ at V_GS = -4.5V contributes to its high efficiency, minimizing losses and improving overall system performance.

The device's fast switching speed is another critical aspect, enabling quick response times in circuits that require high-speed operation. Additionally, the DMP2240UW-7 is characterized by its low input capacitance (C_iss), which further enhances its switching performance and reduces drive power requirements.

For reliability and safety, the DMP2240UW-7 incorporates built-in thermal shutdown and overcurrent protection, ensuring the device operates within safe parameters and providing a longer operational lifespan. Its lead-free and RoHS compliant design also makes it an environmentally friendly choice for manufacturers looking to meet current and future green regulations.

Overall, the DMP2240UW-7 is a versatile and efficient solution for designers seeking a compact, energy-efficient P-Channel MOSFET with robust features for advanced electronic applications.
